New from Jenvey Dynamics is this new Chevy Individual Throttle Body (ITB) kit for fuel injecting your Chevrolet LS1, LS2 and LS6 engine, which includes eight SFD52/0/1 throttle bodies with cross-bank linkage, two EFI inlet manifolds, two fuel rails and eight 60mm length airhorns. Jenvey throttle bodies and all Jenvey throttle body accessories are engineered for motorsport, offering excellent performance, reliability and lightness.
Jenvey says that this kit is ideal for road, track or rally use.
CKCT03 – LS3 Crossover
CKCT04 – LS3 Downdraft
CKCT05T – LS7 Downdraft
Kit performance is enhanced by careful positioning of the EFI fuel injectors being located further upstream than standard and directly in the part throttle turbulence of the butterfly.
This allows increased time/distance for improved fuel mixing increasing torque and power where its needed. Our spindles profiled to minimise cross sectional area at full throttle and an 8 degree shut angle (shallower than most) gives finer control at small throttle openings.
The kits come built and balanced ready to fit you your engine and win races.
Jenvey Dynamics design, develop and manufacture all products in house often working with leading engine builders. Uniquely, with their own foundry, all castings are created in the same factory that they are machined and built in.
Jenvey’s cast systems are significantly lighter than fully CNC parts and all major components are backed up by rig tests of over 1 million cycles.
This Jenvey kit requires an aftermarket ECU but includes throttle cable linkage kit.
An idle air system can help make road cars more useable but is not required with electronic actuation.
They offer a range of injectors but recommend Bosch 412cc for this kit.
Part number ABFLS1-KIT cost £3020 and is available now via www.jenvey.co.uk or call 01746 768 810 ENDS.
